Multifunctional Energy Storage Trolley Case with Portable Pull Rod and High Power Station
Product Details:
Get Best Price Contact Now|
Detail Information |
|||
| Model NO.: | LT-30 | Warranty: | 1year |
|---|---|---|---|
| Output Waveform: | AC Pure Sine Wave | Peak Power: | 6000W |
| AC Output Current: | 15A Max | Charging Time: | 6~7h |
| USB/Type-C: | 18W(Max) | Charging Mode: | AC Adapter, Car, Solar Panel |
| Compatible Appliance: | All | Carrying Mode: | Portable Pull Rod With Pulley |
| AC Output Socket: | All | Product Certification: | CE.Un38.3 |
| Shell Material: | ABS+ Alloy | Battery Capacity: | 48V62.5ah (3000wh) |
| Inverter Type: | Pure Sine Wave | Output Power: | 220~240V-4000W,100~120V-3000W50Hz/60Hz Tunable |
| Colour: | Black (Customizable) | Transport Package: | Un |
| Specification: | LiFePO4 | Origin: | Shenzhen |
| Supply Ability: | 1000 | ||
Product Description
The portable power supply is a power supply device with AC 110V/220V single-phase output and multi-voltage DC output.
The product uses lithium iron phosphate batteries with high efficiency and reliability, providing reliable and high-quality power for your equipment.
With high safety, small size, large capacity, light weight and high power, it provides you with a more convenient mobile power supply and is widely used in outdoor applications, camping, and other fields.
| Battery type | Lithium iron phosphate battery | ||
| Ac output current | 15A MAX | ||
| Ac output voltage | 220V±5% | ||
| Output power | 3000W | ||
| Peak power | 6000W | ||
| Output waveform | Ac pure sine wave | ||
| Waveform distortion | < 3% linear load ,< 8% non-linear load | ||
| Frequency | 50±0.5Hz | ||
| Dc output voltage | 12V | 24V | 48V |
| Dc output current | 10A(MAX) | 12A(MAX) | 50A(MAX) |
| USB/TYPE-C | 18W(MAX) | ||
| Protection function | Short circuit, overload, over temperature, over voltage, over current, under voltage, low temperature, etc | ||
| Charging parameter | 54V/12A | ||
| Battery capacity | 62.5AH | ||
| Charging time | 6~7H | ||
| Cycle life | >2500 times, remaining capacity 80%(5%-95%DOD) | ||
| Apparent dimension | 610*440*250(mm) | ||
| weight | about42.5Kg | ||
It uses long-life, high-safety lithium iron phosphate battery as the power source.
New automatic fire extinguishing device, automatic sensing and active prevention functions.
It has functions such as overcharge and over-discharge, high and low temperature protection, and low battery alarm. There are also protection functions such as short circuit and overload.
The following are individual specific application scenarios of power supplies.
| 1.Outdoor applications:Lighting, fans, projectors, speakers, inflatables, charging, cooking, etc. |
| 2.Home application:TV, computer, rice cooker, electric blanket, washing machine, etc. |
| 3.Manual application:Electric drills, cutters, circular saws, chainsaws, lawn mowers, electric hammers, etc. |
| 4.Common electronic applications:Smart watches, tablets, drones, digital cameras, etc. |
| Note: 12V cigarette lighters cannot be used to heat cigarette butts! It can only power electronic products. Do not use a load that exceeds the rated power of this power supply. The over-power power supply will automatically cut off the output. When the power of the power supply is as low as 20%, please save important data in advance, be prepared to replace the power supply, and charge the power supply in time! |
Q1: How long does the power supply last?
A1: This model LT30 uses about 3 kilowatt hours of electricity. For reference, assumeThe power consumption of the equipment is 500W (electric kettle), then the working time is 3000Wh*0.9/500=~5.4 hours.
A2: Charging time ~6-7 hours Note: Choose 54V/12A charger
Q3: Does the power supply support solar charging?
A3: It supports solar charging, supports 12V-75V DC output, and supports a maximum of 800W.
